Model_Number: DG89 PRODUCT NAME: 5 HP - TE - 1760 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 5 KILOWATTS: 3.7 POLES: 4 NUMBER SPEEDS: 1 RPM: 1760 RPM 2: 1760 RPM 3: 1745 RPM 4: 1440 RPM 5: 1440 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 208-230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 3: 208 VOLTS 4: 380 VOLTS 5: 190 FRME : 184 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6206-2Z-J/C3 SHAFT END BEARING: 6206-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 100 BREAKDOWN TORQUE: 349 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 232 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: J LOCKED ROTOR AMPS: 47 NEMA NOMINAL EFFICIENCY: 89.5 FULL LOAD AMPS PRIMARY: 13.9-12.8/6.4 SERVICE FACTOR AMPS PRIMARY: 17.5-14.5/7.2

Model_Number: DN34 PRODUCT NAME: 150 HP - TE - 1190 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 150 KILOWATTS: 111.9 POLES: 6 NUMBER SPEEDS: 1 RPM: 1190 RPM 4: 980 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 460 VOLTS : 460 VOLTS 4: 380 FRME : 447 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6313-J/C3 SHAFT END BEARING: 6318-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 2025 BREAKDOWN TORQUE: 247 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 147 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: F LOCKED ROTOR AMPS: 1155 NEMA NOMINAL EFFICIENCY: 95.8 FULL LOAD AMPS PRIMARY: 181 SERVICE FACTOR AMPS PRIMARY: 207

Model_Number: DG85 PRODUCT NAME: 3 HP - TE - 3540 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 3 KILOWATTS: 2.2 POLES: 2 NUMBER SPEEDS: 1 RPM: 3540 RPM 2: 3540 RPM 3: 3525 RPM 4: 2920 RPM 5: 2920 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 208-230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 3: 208 VOLTS 4: 380 VOLTS 5: 190 FRME : 182 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6206-2Z-J/C3 SHAFT END BEARING: 6206-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.25 STARTCAPMFD: N\A SHIPPING WEIGHT: 85 BREAKDOWN TORQUE: 336 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 251 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: K LOCKED ROTOR AMPS: 32 NEMA NOMINAL EFFICIENCY: 87.5 FULL LOAD AMPS PRIMARY: 8.4-7.8/3.9 SERVICE FACTOR AMPS PRIMARY: 9.5-9.4/4.7

Model_Number: DL76 PRODUCT NAME: 50 HP - TE - 1780 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 50 KILOWATTS: 37.3 POLES: 4 NUMBER SPEEDS: 1 RPM: 1780 RPM 2: 1780 RPM 4: 1470 RPM 5: 1470 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 4: 380 VOLTS 5: 190 FRME : 326 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6311-2Z-J/C3 SHAFT END BEARING: 6311-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 590 BREAKDOWN TORQUE: 264 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 209 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: G LOCKED ROTOR AMPS: 376 NEMA NOMINAL EFFICIENCY: 94.5 FULL LOAD AMPS PRIMARY: 112/56 SERVICE FACTOR AMPS PRIMARY: 130/65

Model_Number: DM19 PRODUCT NAME: 60 HP - TE - 1785 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 60 KILOWATTS: 44.7 POLES: 4 NUMBER SPEEDS: 1 RPM: 1785 RPM 2: 1785 RPM 4: 1480 RPM 5: 1480 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 4: 380 VOLTS 5: 190 FRME : 364 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6313-2Z-J/C3 SHAFT END BEARING: 6313-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 865 BREAKDOWN TORQUE: 230 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 178 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: G LOCKED ROTOR AMPS: 442.7 NEMA NOMINAL EFFICIENCY: 95 FULL LOAD AMPS PRIMARY: 136/68 SERVICE FACTOR AMPS PRIMARY: 157/79

Model_Number: CY95 PRODUCT NAME: 60 HP - TEFC - 1190 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TEFC HORSEPOWER: 60 KILOWATTS: 44.7 POLES: 6 NUMBER SPEEDS: 1 RPM: 1190 RPM 2: 1190 RPM 4: 985 RPM 5: 985 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 4: 380 VOLTS 5: 190 FRME : 404 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6316-J/C3 SHAFT END BEARING: 6316-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 1160 BREAKDOWN TORQUE: 232 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 161 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: F LOCKED ROTOR AMPS: 442.2 NEMA NOMINAL EFFICIENCY: 94.5 FULL LOAD AMPS PRIMARY: 139/70 SERVICE FACTOR AMPS PRIMARY: 161/80

Model_Number: DT62 PRODUCT NAME: 20 HP - TE - 1770 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 20 KILOWATTS: 14.9 POLES: 4 NUMBER SPEEDS: 1 RPM: 1770 RPM 2: 1770 RPM 3: 1760 RPM 4: 1460 RPM 5: 1460 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 208-230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 3: 208 VOLTS 4: 380 VOLTS 5: 190 FRME : 256 SHAFT CODE: T MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6309-2Z-J/C3 SHAFT END BEARING: 6309-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 340 BREAKDOWN TORQUE: 234 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 231 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: F LOCKED ROTOR AMPS: 140 NEMA NOMINAL EFFICIENCY: 93 FULL LOAD AMPS PRIMARY: 53-47/23.5 SERVICE FACTOR AMPS PRIMARY: 62-54/27.2

Model_Number: DL33 PRODUCT NAME: 25 HP - TE - 3560 PHASETYPE: 3_PHASE MOTOR ENCLOSURE: TE HORSEPOWER: 25 KILOWATTS: 18.6 POLES: 2 NUMBER SPEEDS: 1 RPM: 3560 RPM 2: 3560 RPM 3: 3545 RPM 4: 2940 RPM 5: 2940 HERTZ: 60 HERTZ 2: 50 VOLTS PRIMARY: 208-230/460 VOLTS : 460 VOLTS 2: 230 VOLTS 3: 208 VOLTS 4: 380 VOLTS 5: 190 FRME : 284 SHAFT CODE: TS MOUNTING: HORZ-FOOTED ASSEMBLY POSITION: F1 MOTOR TYPE: CTE OPPOSITE END BEARING: 6310-2Z-J/C3 SHAFT END BEARING: 6310-2Z-J/C3 AMBIENT: 40 ROTATION: DUAL SERVICE FACTOR: 1.15 STARTCAPMFD: N\A SHIPPING WEIGHT: 355 BREAKDOWN TORQUE: 219 BREAKDOWN TORQUE UOM: PERCENT OF FLT LOCKED ROTOR TORQUE: 179 LOCKED ROTOR TORQUE UOM: PERCENT OF FLT INSULATION CLASS: F KVA CODE LETTER: F LOCKED ROTOR AMPS: 174 NEMA NOMINAL EFFICIENCY: 91.7 FULL LOAD AMPS PRIMARY: 66-57/28.7 SERVICE FACTOR AMPS PRIMARY: 0-67/34
